Jinko SunTera G3 is a next-generation containerized energy storage system with a capacity of 6.25 MWh, designed for industrial, utility-scale, and energy projects.
The new generation of SunTera uses high-capacity LFP cells, intelligent liquid cooling, and a multi-level safety system. A standard 20-foot container provides 6.25 MWh of energy storage capacity and can be scaled into BESS installations with capacities of tens or hundreds of MWh.
✅ Capacity — 6.25 MWh
✅ LFP cells — 587/588 Ah
✅ Configurations — 0.5P / 0.25P
✅ System RTE — ≥95%
✅ Cell temperature difference — ≤2.5 °C
✅ Intelligent liquid cooling
✅ IP55
✅ For solar power plants, industrial facilities, microgrids, and grid-scale BESS
✅ Scalable to tens or hundreds of MWh
For the G3, Jinko officially specifies a capacity of 6.25 MWh, 587/588 Ah cells, 0.5P/0.25P configurations, System RTE ≥95%, and a cell temperature difference of ≤2.5 °C.
Ekotechnik Ukraine provides configuration selection, supply, design, and integration of Jinko SunTera G3 into industrial BESS / energy storage systems (ESS) in Ukraine.
Jinko SunTera G3 6.25 MWh — industrial energy storage system (BESS / UZE)
On demand
Price: calculated based on the project configuration
Delivery: CIF Gdańsk / DAP Ukraine
Direct supply from manufacturer: Jinko ESS
Implementation: turnkey BESS
What Is Jinko SunTera G3
Jinko SunTera G3 is the new generation of large-scale containerized energy storage systems from Jinko ESS. A standard 20-foot container houses 6.25 MWh of battery capacity, increasing BESS energy density without increasing the container’s external dimensions.
The system is designed for generation-side, grid-side, and user-side applications, including renewable energy storage, energy shifting, peak shaving, load management, grid support, and large industrial microgrids.
SunTera G3 features high-capacity LFP cells, active balancing, intelligent liquid cooling, and a comprehensive protection architecture covering every level, from individual battery cells to the entire system.
What’s New in Jinko SunTera G3
6.25 MWh in a Single Container:
SunTera G3 increases the capacity of a standard 20-foot container to 6.25 MWh, enabling more stored energy per unit of site area.
New 587/588 Ah LFP Cells: High-capacity cells increase the system’s energy density and reduce the number of internal components.
System RTE ≥95%: Advanced system control and active balancing help improve the efficiency of the energy storage and discharge cycle.
Temperature Difference ≤2.5 °C: The intelligent liquid cooling system maintains a more uniform temperature across battery cells, which is important for BESS stability and service life.
Improved Deployment: Jinko states that more than 90% of pre-commissioning preparation is completed at the factory, reducing the amount of work required on-site.
Technical specifications
| Manufacturer: | Jinko Solar |
|
Battery Type: |
LiFePo4 |
|
System type: |
Containerized BESS / ESS |
|
Nominal capacity: |
6.25 MWh |
|
Battery type: |
LiFePO₄ / LFP |
|
Cell capacity: |
587 / 588 Ah |
| System Configuration: |
1Р416S × 8 |
|
Nominal voltage: |
1331.2 V |
|
Power configurations: |
0.5P / 0.25P — depending on project configuration
|
|
System RTE: |
≥95%
|
|
Maximum cell temperature difference: |
≤2.5 °C |
|
Cooling: |
Intelligent liquid cooling |
|
Container protection rating: |
IP55 |
|
Humidity: |
≤100% RH |
|
Corrosion resistance class: |
C4 / C5 optional |
|
Communication: |
Ethernet / CAN |
|
Operating temperature: |
−40…+55 °C |
|
Dimensions: |
6058 × 2438 × 2896 mm |
|
Weight: |
Approximately 48,000 kg
|
|
Installation altitude: |
Up to 4500 m
|
Get a BESS calculation for your site.
Fill out the form below, we will definitely contact you and answer all your questions
Jinko SunTera G3 or SunTera G2?
|
|
SunTera G2 |
SunTera G3
|
|
Container capacity: |
5,01 MWh
|
6,25 MWh |
|
Form factor: |
20 ft
|
20 ft
|
|
Cells: |
314 Аh
|
587 / 588 Аh |
|
Main advantage: |
Proven platform |
Higher energy density and efficiency |
SunTera G2 remains a solution for projects where a proven 5.01 MWh platform is the priority. SunTera G3 is designed for new large-scale BESS projects where maximum capacity per container, efficient use of site space, and a reduced number of containers are important.
What Makes Up a BESS Based on SunTera G3
SunTera G3 is the battery DC block of an energy storage system. To create a complete BESS, the battery unit must be integrated with power conversion and control equipment.
A typical large-scale BESS architecture includes:
Jinko SunTera G3 → PCS → transformer equipment → switching and protection equipment → EMS → point of connection.
If a solar power plant operates at the site, the EMS coordinates the operation of the solar power plant + BESS + grid + facility load.
Ekotechnik Ukraine selects system components and architecture according to the technical requirements and the parameters of the point of connection.
Applications of Jinko SunTera G3
Industrial facilities: Energy storage, peak shaving, load optimization, and energy consumption management.
Large-scale solar power plants: Storing excess solar generation, energy shifting, and reducing renewable energy curtailment.
Grid-scale BESS: Large-scale energy storage facilities operating on the grid side and supporting power system stability.
Microgrids: Coordinating BESS, solar power plants, generators, and loads through an EMS.
Energy shifting: Shifting electricity use between different time periods.
Peak shaving: Covering peak power demand using stored energy.
Do you have an hourly consumption schedule? Send it to us — we’ll calculate the recommended power and capacity of the BESS for your business..
Fill out the form below, we will definitely contact you and answer all your questions
Industrial Solar Power Plant + Jinko SunTera G3
One of the key applications of SunTera G3 is integration with a large-scale solar power plant.
In this configuration, the solar power plant supplies the facility’s current electricity demand, while available surplus generation can be directed to charge the BESS. The stored electricity is used later according to the EMS control algorithm.
This helps increase the share of solar energy consumed on-site, enables energy shifting, and supports management of the facility’s energy balance.
Ekotechnik Ukraine delivers comprehensive turnkey solar power plant + BESS + EMS solutions, including solar panel installation, solar power plant installation, solar inverters, batteries for solar power systems, and energy storage systems.
6.25 MWh Is Capacity, Not Power
The 6.25 MWh rating indicates how much energy a single SunTera G3 container can store.
BESS power is measured in MW and determines how quickly the system can charge or discharge the stored energy.
SunTera G3 can be deployed in 0.5P or 0.25P configurations. The final AC power output of a project is determined by the PCS, transformer equipment, number of containers, and grid connection parameters.
MW = power
MWh = stored energy
Jinko SunTera G3 Scaling
|
Configurations |
Total Nominal Capacity |
|
1 × SunTera G3
|
6,25 MWh |
|
2 × SunTera G3
|
12,5 MWh
|
|
4 × SunTera G3
|
25 MWh |
|
8 × SunTera G3
|
50 MWh |
The modular containerized architecture allows BESS installations to be built to the required scale. The number of SunTera units, PCS units, transformers, and the EMS configuration are determined individually according to the project's power and energy capacity requirements.
Advantages of Cooperation with Us.
Engineering-based selection
We determine the required system power and capacity based on the actual parameters and energy consumption profile of the facility.
Comprehensive integration
We integrate BESS, PCS, EMS, PV systems and the facility's power grid into a single controllable system.
Jinko ESS supply
We arrange the supply of equipment for industrial BESS projects in Ukraine.
Design and installation
We perform electrical engineering design, equipment installation and system connection.
Technical support
We provide technical support throughout the implementation and operation of the project.
Delivery and Payment.
We deliver equipment directly to the customer's site or to a convenient warehouse of the selected carrier.
Available delivery options:
- delivery across Ukraine via transport companies;
- direct delivery to the customer's site;
- self-pickup from our warehouse by prior arrangement;
- customized logistics for large industrial orders.
For industrial solar power plants, BESS / energy storage systems, and large equipment orders, logistics costs are calculated separately based on the dimensions, weight, route, and unloading requirements.
Before shipment, the equipment is checked for completeness and prepared for safe transportation.
We work with both legal entities and individuals and offer convenient payment options depending on the type of order.
Available payment methods:
- cashless payment to a bank account;
- invoice payment for legal entities;
- advance payment for equipment;
- staged payments for comprehensive turnkey solar projects;
- individual terms for large B2B orders.
After the order is confirmed, our manager prepares the invoice, equipment specification, and, if required, a commercial offer with a detailed list of equipment, delivery times, and payment terms.
For Industrial Projects
For businesses, manufacturing facilities, agricultural enterprises, warehouses, retail chains, and other commercial facilities, we can provide comprehensive project support:
- equipment selection based on the customer's requirements;
- cost calculation for a solar power plant or energy storage system;
- delivery arrangements to the project site;
- solar power plant installation;
- system commissioning and putting it into operation.
Ekotechnik Ukraine operates as an EPC integrator and supplies turnkey solar energy solutions — from equipment supply to complete project implementation.
Ekotechnik Ukraine’s Practical Experience with Jinko BESS
Ekotechnik Ukraine has practical experience integrating Jinko ESS industrial energy storage systems in Ukraine.
The company has implemented projects in which Jinko BESS systems operate alongside solar generation and the industrial facility’s power system.
This hands-on experience enables the Ekotechnik Ukraine team to work not only with energy storage supply but also with the integration of BESS + solar power plant + EMS + the facility’s electrical grid.
❓ FAQ — Frequently Asked Questions
How much does Jinko SunTera G3 cost in Ukraine?
The cost of SunTera G3 and a complete BESS project depends on the number of containers, the 0.5P or 0.25P configuration, PCS capacity, EMS, transformer equipment, logistics, and the scope of installation work. Ekotechnik Ukraine provides individual cost estimates based on the requirements of each project.
What is the capacity of Jinko SunTera G3?
The nominal capacity of one SunTera G3 container is 6.25 MWh.
What is the power output of SunTera G3?
6.25 MWh is the battery’s energy capacity. BESS power is determined by the system configuration, PCS, and number of containers. SunTera G3 supports 0.5P and 0.25P configurations.
What does 0.5P mean in a BESS?
0.5P means that the system’s nominal power is approximately half of its energy capacity per hour. This configuration is used for BESS systems with an approximate two-hour discharge duration. The final parameters are determined by the project design.
Can SunTera G3 be used with a solar power plant?
Yes. SunTera G3 is designed for use in energy storage systems with renewable energy sources and can be integrated with a solar power plant through an appropriate AC or DC architecture.
How many containers are required for a 25 MWh BESS?
Four SunTera G3 containers have a combined nominal capacity of 25 MWh. PCS power and other equipment are determined through a separate engineering assessment.
Can SunTera G3 operate in a microgrid?
Yes. The SunTera series can be used in large-scale microgrid solutions, with an EMS coordinating the BESS, solar generation, diesel generators, and loads.
Does Ekotechnik Ukraine provide turnkey BESS solutions?
Yes. Ekotechnik Ukraine provides engineering and equipment selection, equipment supply, design, installation, integration, and commissioning of industrial energy storage systems.
